Stainless Steel Conductor Bar 40A with Connector Pins

Name: Stainless Steel Conductor Bar 40A with Connector Pins
Brand: Clutch Engineering
SKU: CRA-d72438
Price: 89.99 USD
Availability: OutOfStock

SKU:CRA-d72438

High-performance Stainless Steel Conductor Bar 40A with Connector Pins for efficient crane control. Ampacity of 40A, 5ft length, and -60 to 400°F operating range.

$89.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your crane control system with our Stainless Steel Conductor Bar 40A, precision roll-formed from high-grade stainless steel material for durability. Equipped with connector pins and joint covers, this 5ft conductor bar ensures optimal electrical conductivity with an ampacity of 40A and low resistance. Ideal for industrial usage, meeting support spacing standards and offering a wide operating temperature range from -60 to 400°F.

Product Specifications

Electrical Data Ampacity Continuous Duty

40 A

Electrical Data Impedance Z 60hz

2231 ÂµÎ©/ft

Electrical Data Reactance X 60 Hz

60 ÂµÎ©/ft

Electrical Data Resistance R For Dc At 20 C

2230 ÂµÎ©/ft

Specifications Cover Type

High Heat

Specifications Cross Sectional Area

0.1477 inÂ²

Specifications Expansion Coefficient

0.000007 ÂºF

Specifications Length

5 ft

Specifications Material

Stainless Steel

Specifications Normal Ambient

-60 to 400 ÂºF

Specifications Support Spacing

5 ft

Specifications Weight

3.8 lb | 0.72 lb/ft
