Steel-Fix All Steel 11.0mm Rivet - Large Head for Strong Joints

Steel-Fix All Steel 11.0mm Rivet - Large Head for Strong Joints

STE-9e9139

Premium steel rivet for strong and durable joints in thin-sheet materials. Ideal for automotive applications.

$49.99
$49.99
Sale

Initiate Order

Steel-Fix All Steel 11.0mm Rivet - Large Head for Strong Joints

Steel-Fix All Steel 11.0mm Rivet - Large Head for Strong Joints

$49.99

Quantity: 1

Claim Your Seller Account

Steel-Fix All Steel 11.0mm Rivet - Large Head for Strong Joints

Steel-Fix All Steel 11.0mm Rivet - Large Head for Strong Joints

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Steel-Fix All Steel 11.0mm Rivet with a Large Head is designed for creating strong, vibration-resistant joints in thin-sheet materials. Made of low carbon steel with Zinc Plated Chromium VI Free finish, this rivet ensures durability and reliability. With a nominal shear force of 450 kgf and nominal tensile force of 390 kgf, it meets the stringent requirements of automotive applications. Ideal for window frames and tailored for leading American vehicle manufacturers, this rivet delivers exceptional performance.

Product Specifications

Applications Automotive Application
Window FrameThe Steel Fix fastener is ideal for thin-sheet materials and providing a strong, vibration resistant joint. This solution was tailored made for a leading, American vehicle manufacturer.
Nominal Dimensions Body Length
11.0 mm | 0.433 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
14 mm | 0.551 in
Nominal Dimensions Head Thickness
1.70 mm | 0.067 in
Nominal Dimensions Mandrel Diameter
2.9 mm | 0.114 in
Nominal Dimensions Maximum Grip Range
6.0 mm | 0.236 in
Nominal Dimensions Minimum Grip Range
1.5 mm | 0.059 in
Nominal Forces Nominal Shear Force
450 kgf | 990 lbf
Nominal Forces Nominal Tensile Force
390 kgf | 858 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit | Steel-Fix
Technical Specs Carton Quantity
3000
Technical Specs Head Style
Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
