Steel-Fix All Steel Dome Head Rivet - 4.8mm x 14.0mm
Steel-Fix All Steel Dome Head Rivet - 4.8mm x 14.0mm
SKU:STE-c3b023
Durable Steel Dome Head Rivet for secure fastening in automotive & trailer applications. 4.8mm diameter, 14.0mm body length. Low carbon steel with zinc plating. Reliable & versatile.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Steel-Fix All Steel Dome Head Rivet - 4.8mm x 14.0mm
$89.99
Quantity: 1
Claim Your Seller Account
Steel-Fix All Steel Dome Head Rivet - 4.8mm x 14.0mm
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Steel-Fix All Steel Dome Head Rivet is a durable and versatile fastening solution designed for various applications. With a 4.8mm diameter, 14.0mm body length, and exceptional multi-grip function, this rivet offers secure and reliable performance. Crafted from low carbon steel with zinc plating, it provides strength and corrosion resistance. Suitable for automotive and trailer use, meeting high standards for grip range, shear force, and tensile force.
Product Specifications
Applications Automotive Application
InteriorThe U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Length
14.0 mm | 0.551 in
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Diameter
4.8 mm | 3/16 in
Technical Specs Drillhole Size
4.9 mm | 0.193 in
Technical Specs Head Diameter
9.8 mm | 0.386 in
Technical Specs Head Style
Dome
Technical Specs Head Thickness
1.45 mm | 0.057 in
Technical Specs Mandrel Diameter
2.9 mm | 0.114 in
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
Technical Specs Maximum Grip Range
9.0 mm | 0.354 in
Technical Specs Minimum Grip Range
1.5 mm | 0.059 in
Technical Specs Nominal Shear Force
450 kgf | 990 lbf
Technical Specs Nominal Tensile Force
390 kgf | 858 lbf
