Steel Zinc Plated and Baked Type "AB" Flat Square Drive Self-Tapping Sheet Metal Screw

Name: Steel Zinc Plated and Baked Type "AB" Flat Square Drive Self-Tapping Sheet Metal Screw
Brand: Aspen Fasteners
SKU: SCR-88c287
Price: 49.99 USD
Availability: OutOfStock

SKU:SCR-88c287

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Sheet Metal Screws, or Self-Tapping Screws, are thread cutting fasteners designed to be driven into untapped holes. They generally require a pre-drilled pilot hole (drill size dependent on the screw diameter and material thickness). They are available with a variety of points and thread styles in order to accommodate different material thickness.

Product Specifications

Additional Information

Also known as self-tapping screws, these are mostly used in thin gauge sheet metal applications.Type "AB" sheet metal tapping screws feature a sharp point and fine threading.Flat countersunk head screws sit flush with the surface of the material they are inserted into.

Specifications Coating

Zinc Plated and Baked

Specifications Coating Color

Clear

Specifications Core Hardness Rating

Rockwell C28-C38

Specifications Drive Style

Internal Square Drive

Specifications Head Detail

82 Degree Countersink

Specifications Head Style

Flat Countersunk Head

Specifications Industry Standards And Specifications

American Society of Mechanical Engineers (ASME B18.6.3) | Society of Automotive Engineers (SAE-J933)

Specifications Material

Steel

Specifications Material Processes

Case Hardened

Specifications Minimum Hardness Rating

Rockwell C45

Specifications Style

Type "AB"

Specifications System Of Measurement

Inch

Specifications Thread Direction

Right-Hand Thread

Specifications Thread Length

Full Thread

Steel Zinc Plated and Baked Type "AB" Flat Square Drive Self-Tapping Sheet Metal Screw
