Steel Zinc Plated and Baked Type "B" Flat Undercut 6Lobe Torx® Drive Self-Tapping Sheet Metal Screw

Name: Steel Zinc Plated and Baked Type "B" Flat Undercut 6Lobe Torx® Drive Self-Tapping Sheet Metal Screw
Brand: Aspen Fasteners
SKU: SCR-f4d85f
Price: 49.99 USD
Availability: OutOfStock

SKU:SCR-f4d85f

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Sheet Metal Screws, or Self-Tapping Screws, are thread cutting fasteners designed to be driven into untapped holes. They generally require a pre-drilled pilot hole (drill size dependent on the screw diameter and material thickness). They are available with a variety of points and thread styles in order to accommodate different material thickness.

Product Specifications

Additional Information

Also known as self-tapping screws, these are mostly used in thin gauge sheet metal applications.Type "B" sheet metal tapping screws feature a blunt point and fine threading.A 6-lobe recess is also known as a hexalobular internal drive.

Specifications Coating

Zinc Plated and Baked

Specifications Coating Color

Clear

Specifications Core Hardness Rating

Rockwell C28-C38

Specifications Drive Detail

Torx® Generic Alternative

Specifications Drive Style

6 Lobe Drive

Specifications Head Detail

82 Degree Countersink

Specifications Head Style

Flat Countersunk Undercut Head

Specifications Industry Standards And Specifications

American Society of Mechanical Engineers (ASME B18.6.3) | Society of Automotive Engineers (SAE-J933)

Specifications Material

Steel

Specifications Material Processes

Case Hardened

Specifications Minimum Hardness Rating

Rockwell C45

Specifications Style

Type "B"

Specifications System Of Measurement

Inch

Specifications Thread Direction

Right-Hand Thread

Specifications Thread Length

Full Thread
