Stelock All Steel Dome Head Rivet - 19.0mm Body Length, Zinc Plated Chromium (Cr) VI Free
Stelock All Steel Dome Head Rivet - 19.0mm Body Length, Zinc Plated Chromium (Cr) VI Free
SKU:STE-01c7f6
Stelock All Steel Dome Head Rivet - Durable, Zinc Plated, High Strength Rivet for Heavy-Duty Applications
Regular price
$65.99
Regular price
Sale price
$65.99
Unit price
per
Initiate Order
Stelock All Steel Dome Head Rivet - 19.0mm Body Length, Zinc Plated Chromium (Cr) VI Free
$65.99
Quantity: 1
Claim Your Seller Account
Stelock All Steel Dome Head Rivet - 19.0mm Body Length, Zinc Plated Chromium (Cr) VI Free
$65.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Stelock All Steel Dome Head Rivet features a sturdy low carbon steel body with a Zinc Plated Chromium (Cr) VI Free finish, ensuring durability and corrosion resistance. It comes in a carton of 2000 pieces, meeting high-volume requirements. With a 19.0mm body length and a mandrel diameter of 4.0mm, this rivet offers a secure grip range of 9.0mm to 12.0mm. It boasts a nominal shear force of 960 kgf and a nominal tensile force of 550 kgf, making it ideal for heavy-duty applications. Compliant with industry standards, this rivet is a reliable choice for both consumer and institutional buyers.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
19.0 mm | 0.748 in
Nominal Dimensions Diameter
6.0 mm | 0.236 in
Nominal Dimensions Drillhole Size
6.1 to 6.3 mm | 0.240 to 0.248 in
Nominal Dimensions Head Diameter
12.0 mm | 0.472 in
Nominal Dimensions Head Thickness
1.80 mm | 0.071 in
Nominal Dimensions Mandrel Diameter
4.0 mm | 0.157 in
Nominal Dimensions Maximum Grip Range
12.0 mm | 0.472 in
Nominal Dimensions Minimum Grip Range
9.0 mm | 0.354 in
Nominal Forces Nominal Shear Force
960 kgf | 2115 lbf
Nominal Forces Nominal Tensile Force
550 kgf | 1210 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit | Stelock
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
