Strybuc Bronze Finish Surface Vertical Rod Exit Device

Strybuc Bronze Finish Surface Vertical Rod Exit Device

COM-db96f6

Secure double doors without mullions with the Strybuc Bronze Finish Panic Device, meeting ANSI Grade 2 & UL standards.

$289.99
$289.99
Sale

Initiate Order

Strybuc Bronze Finish Surface Vertical Rod Exit Device

Strybuc Bronze Finish Surface Vertical Rod Exit Device

$289.99

Quantity: 1

Claim Your Seller Account

Strybuc Bronze Finish Surface Vertical Rod Exit Device

Strybuc Bronze Finish Surface Vertical Rod Exit Device

$289.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Strybuc Bronze Finish Surface Vertical Rod Exit Device is designed for double doors without mullions, making it ideal for commercial applications. This reversible panic device, crafted from extruded anodized aluminum with stainless steel springs, ensures durability and security. Meeting American National Standards Institute (ANSI) A156.3 Grade 2 and Underwriters Laboratories (UL) Listed standards, this device offers top-notch quality for new constructions or renovations. With adjustable features like door height, backset, and hand orientation, it provides flexibility for varied door configurations.

Product Specifications

Accessories Accessories
Item# 19-752Item Name - Night Latch Handle SetFinish - AluminumItem# 19-604ALItem Name - Entry LeverFinish - AluminumItem# 19-604BZItem Name - Entry LeverFinish - BronzeItem# 19-753Item Name - Dummy Handle SetFinish - AluminumItem# 19-619ALItem Name - Storeroom LeverFinish - AluminumItem# 19-1038ALItem Name - Entry Handle SetDescription - with CylinderFinish - AluminumItem# 19-1035ALItem Name - Entry Handle SetDescription - no CylinderFinish - AluminumItem# 9-618ALItem Name - Passage LeverFinish - AluminumItem# 19-751Item Name - Exit Only PlateFinish - AluminumItem# 19-1034ALItem Name - Entry BallFinish - AluminumItem# 19-568Item Name - Rim CylinderFinish - AluminumItem# 19-568BZItem Name - Rim CylinderFinish - BronzeItem# 19-749Item Name - Pull TrimFinish - AluminumItem# 19-750Item Name - Dummy Pull TrimFinish - Aluminum
Features Features
Material: Extruded anodized aluminum push bar, stainless steel springsLatch: Top Pullman type, Bottom bolt assemblyDoor Height: 7' standardBackset: 2-3/4" on 4-1/2" minimum stile width -if less than 4-1/2" backset becomes half of the exposed stile widthStrike: Top-surface mounted, Bottom-flat mortise or into threshold, vertical/rim application use DBLST double dr. strikeProjection: 2-1/2" - 1-7/8" doggedStile: 4-1/2" minimumHanding: Reversible, non-handedDoor Thickness: 1-3/4" standardDoor Width: 36", can be field sized to 30"Mounting Height: Recommended installation at 41" from finished floor to center line of push rail.Fasteners: Furnished with sheet metal and machine screwsCylinder not included.Dogging: 1/2 turn hex key
Specifications Finish
Bronze
Specifications Industry Standards
American National Standards Institute (ANSI) A156.3 Grade 2 | Underwriters Laboratories (UL) Listed
