Super Orlock™ Protruding Head Rivet - 22.5mm Body Length
Super Orlock™ Protruding Head Rivet - 22.5mm Body Length
SKU:SUP-44a381
Experience unmatched strength with the Super Orlock™ 22.5mm Protruding Head Rivet - perfect for high-force applications. Zinc-coated chromium finish ensures durability and security.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Super Orlock™ Protruding Head Rivet - 22.5mm Body Length
$49.99
Quantity: 1
Claim Your Seller Account
Super Orlock™ Protruding Head Rivet - 22.5mm Body Length
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Introducing the Super Orlock™ 22.5mm Protruding Head Rivet, engineered for extra-high forces with unparalleled shear and tensile strengths. Constructed with low carbon steel body and austenitic stainless steel mandrel, it ensures exceptional durability and security. The zinc-coated chromium finish enhances longevity, making it ideal for rail transport, renewable energy, and other demanding applications. Trust in the Super Orlock™ for superior performance and reliability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Rail Transport Application
Cable CarWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an extremely secure, vibrationâresistant joint. The stainless steel version is also commonly used for this type of application.TrainsWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an exceptionally secure, vibrationâresistant joint. The stainless steel version is also available in a variety of grades.
Applications Renewable Energy Application
Solar FramesThe Orlock⢠Stainless Steel is commonly used in a variety of solar applications worldwide. This stainless steel rivet provides a permanent, secure joint in the most severe climate conditions. Also available in 316.
Nominal Dimensions Body Length
22.5 mm | 0.886 in
Nominal Dimensions Diameter
6.5 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.7 to 6.9 mm | 0.263 to 0.271 in
Nominal Dimensions Head Diameter
13.0 mm | 0.512 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
16.5 mm | 0.650 in
Nominal Dimensions Minimum Grip Range
13.0 mm | 0.512 in
Nominal Forces Nominal Shear Force
810 kgf | 1782 lbf
Nominal Forces Nominal Tensile Force
810 kgf | 1782 lbf
Technical Specs Body Finish
Zinc Coated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit | Super Orlockâ¢
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Protruding
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304
