Super Orlock Steel Large Head Rivet - 20.5mm Body Length
Super Orlock Steel Large Head Rivet - 20.5mm Body Length
SKU:SUP-14e000
Super Orlock Steel Rivet with 20.5mm Body Length, high strength, and wide grip range for secure joints in rail transport applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Super Orlock Steel Large Head Rivet - 20.5mm Body Length
$45.99
Quantity: 1
Claim Your Seller Account
Super Orlock Steel Large Head Rivet - 20.5mm Body Length
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Super Orlock Steel Large Head Rivet with a 20.5mm body length is the ultimate solution for applications requiring extra-high forces. Made of low carbon steel with zinc-plated chromium finish, it offers superior shear and tensile strengths, a wide grip range of 11.0mm to 14.5mm, and exceptional vibration resistance. Ideal for rail transport applications like cable cars and trains, this rivet ensures a secure and durable joint, meeting the demanding requirements of heavy-duty projects.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Rail Transport Application
Cable CarWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an extremely secure, vibrationâresistant joint. The stainless steel version is also commonly used for this type of application.TrainsWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an exceptionally secure, vibrationâresistant joint. The stainless steel version is also available in a variety of grades.
Nominal Dimensions Body Length
20.5 mm | 0.807 in
Nominal Dimensions Diameter
6.5 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.7 to 6.9 mm | 0.263 to 0.271 in
Nominal Dimensions Head Diameter
16.3 mm | 0.642 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
14.5 mm | 0.571 in
Nominal Dimensions Minimum Grip Range
11.0 mm | 0.433 in
Nominal Forces Nominal Shear Force
1570 kgf | 3454 lbf
Nominal Forces Nominal Tensile Force
810 kgf | 1782 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit | Super Orlockâ¢
Technical Specs Carton Quantity
1500
Technical Specs Head Style
Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
