Super Orlock⢠14.5mm Steel X-Large Head Rivet
Super Orlock⢠14.5mm Steel X-Large Head Rivet
SKU:SUP-b15d20
Enhanced strength & vibration-resistance in a 14.5mm steel rivet for demanding applications
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Super Orlock⢠14.5mm Steel X-Large Head Rivet
$45.99
Quantity: 1
Claim Your Seller Account
Super Orlock⢠14.5mm Steel X-Large Head Rivet
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Super Orlock⢠14.5mm Steel X-Large Head Rivet is designed for applications requiring extra-high forces. Made of low carbon steel with a zinc-plated chromium finish, it offers superior shear and tensile strengths. With a wide grip range of 5.0mm to 8.5mm, it ensures a secure, vibration-resistant joint. Ideal for rail transport applications like cable cars and trains, this rivet is known for its reliability and durability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Rail Transport Application
Cable CarWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an extremely secure, vibrationâresistant joint. The stainless steel version is also commonly used for this type of application.TrainsWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an exceptionally secure, vibrationâresistant joint. The stainless steel version is also available in a variety of grades.
Nominal Dimensions Body Length
14.5 mm | 0.571 in
Nominal Dimensions Diameter
6.5 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.7 to 6.9 mm | 0.263 to 0.271 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
8.5 mm | 0.335 in
Nominal Dimensions Minimum Grip Range
5.0 mm | 0.197 in
Nominal Forces Nominal Shear Force
1400 kgf | 3080 lbf
Nominal Forces Nominal Tensile Force
810 kgf | 1782 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit | Super Orlockâ¢
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
