Super Orlock⢠18.5mm Steel Rivet
Super Orlock⢠18.5mm Steel Rivet
SKU:SUP-8df2e5
Premium Super Orlockâ„¢ 18.5mm Steel Rivet - Superior strength, wide grip range, ideal for high-force applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Super Orlock⢠18.5mm Steel Rivet
$49.99
Quantity: 1
Claim Your Seller Account
Super Orlock⢠18.5mm Steel Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Super Orlock⢠18.5mm Steel Rivet is engineered for applications requiring extra-high forces, offering superior shear and tensile strengths along with a wide grip range. Made of low carbon steel with a Zinc Plated Chromium VI Free finish, this rivet ensures durability and security in critical installations. With a large head design and precise nominal dimensions, it provides reliable fastening solutions for rail transport applications like cable cars and trains. Trust in the robust construction and vibration resistance of the Super Orlock™ for your most demanding projects.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Rail Transport Application
Cable CarWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an extremely secure, vibrationâresistant joint. The stainless steel version is also commonly used for this type of application.TrainsWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an exceptionally secure, vibrationâresistant joint. The stainless steel version is also available in a variety of grades.
Nominal Dimensions Body Length
18.5 mm | 0.728 in
Nominal Dimensions Diameter
6.5 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.7 to 6.9 mm | 0.263 to 0.271 in
Nominal Dimensions Head Diameter
16.3 mm | 0.642 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
12.5 mm | 0.492 in
Nominal Dimensions Minimum Grip Range
9.0 mm | 0.354 in
Nominal Forces Nominal Shear Force
1570 kgf | 3454 lbf
Nominal Forces Nominal Tensile Force
810 kgf | 1782 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit | Super Orlockâ¢
Technical Specs Carton Quantity
1500
Technical Specs Head Style
Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
