Super Orlock⢠22.5mm Steel X-Large Head Rivet
Super Orlock⢠22.5mm Steel X-Large Head Rivet
SKU:SUP-5f02c3
Meet high-force demands with the Super Orlockâ„¢ 22.5mm Steel X-Large Head Rivet. Superior strength, secure joints, and corrosion resistance for rail transport applications.
Regular price
$37.99
Regular price
Sale price
$37.99
Unit price
per
Initiate Order
Super Orlock⢠22.5mm Steel X-Large Head Rivet
$37.99
Quantity: 1
Claim Your Seller Account
Super Orlock⢠22.5mm Steel X-Large Head Rivet
$37.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Super Orlock⢠22.5mm Steel X-Large Head Rivet is engineered for applications demanding extra-high forces. With superior shear and tensile strengths, this rivet ensures a secure, vibration-resistant joint. Constructed with low carbon steel and zinc plated chromium VI free finish, it offers durability and corrosion resistance. Ideal for rail transport applications like cable cars and trains, this rivet is available in stainless steel variants meeting rigorous industry standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Rail Transport Application
Cable CarWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an extremely secure, vibrationâresistant joint. The stainless steel version is also commonly used for this type of application.TrainsWhen extra forces are required, the Super Orlock⢠is the solution. The Super Orlock⢠provides higher shear and tensile strengths, a wider grip range and creates an exceptionally secure, vibrationâresistant joint. The stainless steel version is also available in a variety of grades.
Nominal Dimensions Body Length
22.5 mm | 0.886 in
Nominal Dimensions Diameter
6.5 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.7 to 6.9 mm | 0.263 to 0.271 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
16.5 mm | 0.650 in
Nominal Dimensions Minimum Grip Range
13.0 mm | 0.512 in
Nominal Forces Nominal Shear Force
1570 kgf | 3454 lbf
Nominal Forces Nominal Tensile Force
810 kgf | 1782 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit | Super Orlockâ¢
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
