Sure Flow YF125 2 Inch Cast Iron Class 125 Flanged Y Strainer
Sure Flow YF125 2 Inch Cast Iron Class 125 Flanged Y Strainer
SKU:YST-0da19c
Precision filtration with Sure Flow YF125 2 Inch Cast Iron Class 125 Flanged Y Strainer. Durable design, removable stainless steel screen, and high operating pressures. ISO 9001:2008 certified.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Sure Flow YF125 2 Inch Cast Iron Class 125 Flanged Y Strainer
$299.99
Quantity: 1
Claim Your Seller Account
Sure Flow YF125 2 Inch Cast Iron Class 125 Flanged Y Strainer
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Sure Flow YF125 2 Inch Cast Iron Class 125 Flanged Y Strainer is expertly designed for precise filtration in horizontal or vertical pipelines. Featuring a high-tensile ASTM A126 Class B cast iron body and cover, this strainer ensures durability and reliability. The removable stainless steel screen with a 3/64" perforated standard screen effectively filters debris while the flanged blow-off cover simplifies maintenance. With operating pressures up to 125 psi for steam and 200 psi for water, oil, and gas, this strainer is ideal for a variety of applications. Certified to ISO 9001:2008 standards, it combines quality and performance for industrial use.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Construction Body Material
High Tensile American Society for Testing and Materials (ASTM) A126 Class B Cast Iron
Construction Cover Material
High Tensile American Society for Testing and Materials (ASTM) A126 Class B Cast Iron
Construction Plug Material
High Tensile American Society for Testing and Materials (ASTM) A126 Class B Cast Iron
Construction Screen Material
Stainless Steel
Dimensions Blow Off National Pipe Thread Npt Size
1/2 in
Dimensions Dimension A
7 7/8 in
Dimensions Dimension B
5 1/4 in
Dimensions Prefix Size
0200
Dimensions Shipping Weight
21 lb
Dimensions Size
2 in
Industry Standardscertifications Industry Standardscertification
International Organization for Standardization (ISO) 9001:2008 (Intertek)
Note Note
Must specify if for steam serviceManufacturer reserves the right to modify dimensions, materials, or design.
Operating Pressures And Temperatures Pressure At 150 Degree Fahr
200 psi
Operating Pressures And Temperatures Pressure At 344 Degree Fahr
125 psi
Specifications Connection Type
Flanged
Specifications Orientation
Horizontal | Vertical
Standard Screens Perforated Standard Screen
3/64 in
Standard Screens Screen Opening
0.045 in
