Switch Mode Power Supply - Wall Plug-In
Switch Mode Power Supply - Wall Plug-In
SKU:WAL-d2d80d
Efficient Triad wall plug-in Switch Mode Power Supply with regulated output, compact design, and tamper-proof enclosure for safe and stable power.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Switch Mode Power Supply - Wall Plug-In
$29.99
Quantity: 1
Claim Your Seller Account
Switch Mode Power Supply - Wall Plug-In
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your product designs efficiently with our Triad prepackaged wall plug-in Switch Mode Power Supply. These power sources reduce noise levels, size, and weight of end products by eliminating the need for internal cooling devices. With regulated output voltage, our compact and tamper-proof power supplies keep heat away from sensitive circuits, providing a safe and stable power output. Featuring a wide range of popular voltages, power levels, and reversed polarity options, our supplies meet EIAS 2007 energy efficiency requirements and offer Level IV and V efficiency. Complete with a generous 6-foot cord, these supplies operate at 50-60 Hz frequency, ensuring reliable performance.
Product Specifications
Case Dimensions Depth D
1.37 in | 34.80 mm
Case Dimensions Height H
2.67 in | 67.70 mm
Case Dimensions Width W
1.81 in | 45.90 mm
Output Plug Dimensions Inside Diameter Id
0.098±0.004 in | 2.5 mm
Output Plug Dimensions Length L
0.433±0.020 in | 11 mm
Output Plug Dimensions Outside Diameter Od
0.217±0.004 in | 5.5 mm
Specifications 2007 Eisa Efficiency
VI
Specifications Input Operating Frequency
50 Hz | 60 Hz
Specifications Input Voltage Ac
100 to 240 V
Specifications Maximum Power
11.88 W
Specifications Output Current
0.88 A
Specifications Output Current Dc
0.88 A
Specifications Output Voltage Dc
13.5 V
Specifications Polarity Center
Negative
Specifications Type
Switchmode
