Symmetric Torque Friction Hinge - 1.8 N.m Open/Close, Natural Finish
Symmetric Torque Friction Hinge - 1.8 N.m Open/Close, Natural Finish
SKU:IND-479046
Achieve precise panel hinging with the Symmetric Torque Friction Hinge. 1.8 N·m to Open and Close, Die Cast Zinc, Stainless Steel Pin.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Symmetric Torque Friction Hinge - 1.8 N.m Open/Close, Natural Finish
$29.99
Quantity: 1
Claim Your Seller Account
Symmetric Torque Friction Hinge - 1.8 N.m Open/Close, Natural Finish
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance panel hinging with precision using the Symmetric Torque Friction Hinge. With a Torque of 1.8 N·m to Open and Close, this hinge ensures smooth operation and durability. Made of Die Cast Zinc and Stainless Steel hinge pin, it offers reliable security. The Natural Surface Finish adds a sleek look while meeting institutional-grade standards for consistent torque performance over 25,000 cycles.
Product Specifications
Specifications Hinge Leaves Material
Die Cast Zinc
Specifications Hinge Pin Material
Stainless Steel (SS)
Specifications Metal Hinge With Constant Friction
Symmetric Torque
Specifications Mounting
Screw
Specifications Special Features
Life: Within 20 Percent of stated torque after 25,000 cycles.
Specifications Surface Finish
Natural
Specifications Torque To Close
1.8 N·m | 16.0 in·lb
Specifications Torque To Open
1.8 N·m | 16.0 in·lb
