Symmetric Torque Friction Hinge - 2.3 N.m Natural Finish
Symmetric Torque Friction Hinge - 2.3 N.m Natural Finish
SKU:IND-881bcf
Experience smooth panel hinging with the Symmetric Torque Friction Hinge - 2.3 N.m torque, durable materials, and constant friction technology for reliable operation.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Symmetric Torque Friction Hinge - 2.3 N.m Natural Finish
$24.99
Quantity: 1
Claim Your Seller Account
Symmetric Torque Friction Hinge - 2.3 N.m Natural Finish
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Symmetric Torque Friction Hinge offers precise control with a torque of 2.3 N·m for opening and closing, ensuring smooth operation for hinging panels. Crafted with die-cast zinc hinge leaves and stainless steel hinge pin, this hinge guarantees durability and reliability. Its natural surface finish and constant friction technology provide a seamless user experience. With a special feature of maintaining torque within 20% after 25,000 cycles, this hinge is designed for long-lasting performance in industrial environments.
Product Specifications
Specifications Hinge Leaves Material
Die Cast Zinc
Specifications Hinge Pin Material
Stainless Steel (SS)
Specifications Metal Hinge With Constant Friction
Symmetric Torque
Specifications Mounting
Screw
Specifications Special Features
Life: Within 20 Percent of stated torque after 25,000 cycles.
Specifications Surface Finish
Natural
Specifications Torque To Close
2.3 N·m | 20.4 in·lb
Specifications Torque To Open
2.3 N·m | 20.4 in·lb
