SYZR Series Low Set Super-Low Sulfur Expandable Graphite
SYZR Series Low Set Super-Low Sulfur Expandable Graphite
SKU:SYZ-d2f7c3
Discover SYZR Series Expandable Graphite - the halogen-free, low-smoke, and high-purity flame retardant solution ideal for polyurethanes, coatings, and various applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
SYZR Series Low Set Super-Low Sulfur Expandable Graphite
$49.99
Quantity: 1
Claim Your Seller Account
SYZR Series Low Set Super-Low Sulfur Expandable Graphite
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SYZR Series Expandable Graphite offers a superior flame retardant solution with halogen-free, low smoke, and reduced heat release properties. With a purity of ≥99%, this expandable graphite reaches an expansion temperature of 150 ºC and an expansion volume of ≥200 ml/g. Ideal for polyurethanes, coatings, and more, its versatility and technical excellence make it a top choice for applications requiring exceptional flame retardancy.
Product Specifications
Additional Information
ADT Expandable Graphite is a material based on natural graphite ore. The ore is treated with sulfuric acid in what is called an intercalation process. The material is washed and neutralized to prevent corrosion of metal parts when processed by the user. Excessive shear should be avoided. ADT Expandable Graphite additives may be used in polyurethanes, sealants, coatings, and polymers.ADT Expandable Graphite additives may also be used in conjunction with other flame retardant additives to provide improved flame retardant Properties to a material.This halogen-free flame retardant has a wide range of expansion temperature and can be used for foams, paints, resins, rubber and more.Expandable Graphite is a stratiform graphite and contains acids between each stratums. Once it’s heated, acid generates gas and stratiforms are expanded. This expanded stable structure puts off a fire by cutting off the supply of air. (LOI is 28 by adding 15% in Polypropylene)
Advantages
Can be expanded by heat to make non-flammable stable layerStarting expansion temperature is 150 to 300 CCan be used with other flame retardants such as Zinc Borate or Ammonium PolyphosphateHalogen-freeHeavy metal freeVarious grades with different particle sizes, expansion temperatures and expansion volumes available
Applications
E.G. has been used as non-halogen flame retardant in various applications such asPolyurethane foamEVA foamRoofingNon-flammable paintConstruction materialsSealingsPolyolefin resinThermoplastic resinThermoset resinRubber
Note
Information herein is accurate to the best of our knowledge. Suggestions are made without warranty or guarantee of results. Before using, user should determine the suitability of the intended use and user assumes risk and liability in connection therewith. We do not suggest violation of any existing patents or give permission to practice any patented invention without a license.
Technical Specs Benefits
ADT Expandable Graphite flame retardant additives can be formulated to provide a flame retarded system with following advantages.Halogen-FreeLow SmokeReduced Heat ReleaseInsulatingLower in Toxic GasesNon-Dripping
Technical Specs Expansion Temperature
150 ºC
Technical Specs Expansion Temperature Tolerance
10
Technical Specs Expansion Volume
≥200 ml/g
Technical Specs Purity
≥99 %
Properties Bulk Density
0.45 to 0.65 g/cm³
Properties Color
Black with Metallic Sheen
Properties Free Acid
0.8 mg/g NaOH
Properties Free Water
1 %
Properties Impurity
Trace of Silica and/or Mica
Properties Particle Size
+80 mesh
Properties Potential Of Hydrogen Ph
5~8
Properties Specific Gravity
2.2 to 2.3 g/cm³
Properties Water Solubility
<0.1 %
