T-Front Mounted Pneumatic Timer Block, 0.1-3s On Delay, Shamrock Controls
T-Front Mounted Pneumatic Timer Block, 0.1-3s On Delay, Shamrock Controls
SKU:CON-e0e5fc
Enhance control systems with precision timing using Shamrock Controls' T-Front Mounted Pneumatic Timer Block (0.1-3s).
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
T-Front Mounted Pneumatic Timer Block, 0.1-3s On Delay, Shamrock Controls
$129.99
Quantity: 1
Claim Your Seller Account
T-Front Mounted Pneumatic Timer Block, 0.1-3s On Delay, Shamrock Controls
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The T and F-Range Front Mounted Pneumatic Timer Block offers precision timing capabilities with a range of 0.1 to 3 seconds. Engineered by Shamrock Controls, this timer block features reliable performance with 5 million mechanical cycles, auxiliary contacts for versatile functionality, and insulation resistance exceeding 10 MΩ. Operating temperature range from -40 to 70°C ensures adaptability in various environments. Compliant with CSA C22-2 No. 14, this timer block meets stringent industry standards for durability and accuracy.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Accuracy Only Valid For Setting Range
15 %
Specifications Auxiliary Contacts Normally Closed Nc
1
Specifications Auxiliary Contacts Normally Open No
1
Specifications Frequency Of Operational Current
25 to 400 Hz
Specifications Indicated On The Front Face Per Degree Celsius C
0.25 %
Specifications Insulation Resistance
> 10 MΩ
Specifications Mechanical Life
5 Million Cycles
Specifications Minimum Switching Current Capacity I Min
5 mA
Specifications Minimum Switching Voltage Capacity U Min
17 V
Specifications Number Of Contacts
2
Specifications Permissible Short Time Current Rating For At 100
140 A
Specifications Permissible Short Time Current Rating For At 1 Se
100 A
Specifications Permissible Short Time Current Rating For At 500
120 A
Specifications Range
0.1 to 3 s
Specifications Rated Insulation Voltage Ui Conforming To Canadia
690 V
Specifications Rated Operational Voltage Ue
660 V
Specifications Rated Thermal Current For Ambient Temperature 40
10 A
Specifications Repeat Accuracy
5 %
Specifications Time Delay Ambient Air Temperature For Operation
-40 to 70 ºC
