Tan Paper Tapered Plug - 1 1/4 in NPT
Tan Paper Tapered Plug - 1 1/4 in NPT
SKU:TAP-394d18
Sustainable Tan Paper Tapered Plug for 1 1/4 in NPT threads, withstands up to 400 °F, RoHS compliant.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Tan Paper Tapered Plug - 1 1/4 in NPT
$29.99
Quantity: 1
Claim Your Seller Account
Tan Paper Tapered Plug - 1 1/4 in NPT
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Tan Paper Tapered Plug is a sustainable and cost-effective masking solution designed for temperatures up to 400 °F. These recyclable paper plugs ensure no condensation, with precise dimensions to fit 1 1/4 in NPT threads. Manufactured to RoHS standards, this product offers reliability and environmental compliance for a wide range of applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Manufacturing Notes 0
Due to the material, these Tapered Paper Plugs may have minor dimensional variation due to changes in relative humidity.MOCAP stocks paper tapered plugs in many sizes for immediate shipment.MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need.Micro-Packs are only available online.Tolerances: Part dimensions are typical from a measured lot. Individual pieces may vary.Due to the material, this product may have minor dimensional variation due to changes in relative humidity.Flange concentricity may vary.Due to papers natural structure, the product may be oblong in free state. This will generally aid in the products retention capability.
Specifications Applications
Masking
Specifications Box Quantity
3000
Specifications Color
Tan
Specifications Flange Outer Diameter Dimension F
2.118 in | 53.8 mm
Specifications Large End Outer Diameter Dimension B
1.776 in | 45.1 mm
Specifications Length Dimension E
0.689 in | 17.5 mm
Specifications Material
Paper
Specifications Micro Pack Quantity
60
Specifications Mini Pack Quantity
600
Specifications Small End Outer Diameter Dimension A
1.496 in | 38.0 mm
Specifications Standards
RoHS Compliant
Specifications To Fit Female Npt Thread Size
1 1/4 in
Specifications Wall Thickness
0.025 in
Specifications Wall Thickness Tolerance
0.002
