Tan Paper Tapered Plugs for NPT Application

Tan Paper Tapered Plugs for NPT Application

TAP-a244b9

Eco-friendly Tan Paper Tapered Plugs for precise masking in industrial applications. RoHS compliant and heat-resistant up to 400°F.

$99.99
$99.99
Sale

Initiate Order

Tan Paper Tapered Plugs for NPT Application

Tan Paper Tapered Plugs for NPT Application

$99.99

Quantity: 1

Claim Your Seller Account

Tan Paper Tapered Plugs for NPT Application

Tan Paper Tapered Plugs for NPT Application

$99.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
Discover our environmentally friendly Tan Paper Tapered Plugs, ideal for low-to-high temperature masking applications. These paper plugs are recyclable and RoHS compliant, featuring precise dimensions to fit 1/8 to 3 in female NPTs. With a temperature resistance of up to 400°F and flanged design for secure fitting, these plugs offer reliability and eco-conscious masking solutions for various industrial needs.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Manufacturing Notes 0
Due to the material, these Tapered Paper Plugs may have minor dimensional variation due to changes in relative humidity.MOCAP stocks paper tapered plugs in many sizes for immediate shipment.MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need.Micro-Packs are only available online.Tolerances: Part dimensions are typical from a measured lot. Individual pieces may vary.Due to the material, this product may have minor dimensional variation due to changes in relative humidity.Flange concentricity may vary.Due to papers natural structure, the product may be oblong in free state. This will generally aid in the products retention capability.
Specifications Applications
Masking
Specifications Box Quantity
13500
Specifications Color
Tan
Specifications Flange Outer Diameter Dimension F
0.760 in | 19.3 mm
Specifications Large End Outer Diameter Dimension B
0.575 in | 14.6 mm
Specifications Length Dimension E
0.417 in | 10.6 mm
Specifications Material
Paper
Specifications Micro Pack Quantity
100
Specifications Mini Pack Quantity
1000
Specifications Small End Outer Diameter Dimension A
0.469 in | 11.9 mm
Specifications Standards
RoHS Compliant
Specifications Wall Thickness
0.025 in
Specifications Wall Thickness Tolerance
0.002
