Tan Paper Tapered Plugs for NPT Applications
Tan Paper Tapered Plugs for NPT Applications
SKU:TAP-219f36
Environmentally friendly Tan Paper Tapered Plugs for masking NPT applications, heat resistant up to 400°F.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Tan Paper Tapered Plugs for NPT Applications
$29.99
Quantity: 1
Claim Your Seller Account
Tan Paper Tapered Plugs for NPT Applications
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Discover our environmentally friendly and cost-effective Tan Paper Tapered Plugs designed for masking applications. These recyclable plugs, resistant up to 400°F, are perfect for various temperature needs. With precise dimensions and RoHS compliance, they provide a reliable solution for NPT sizing requirements.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Manufacturing Notes 0
Due to the material, these Tapered Paper Plugs may have minor dimensional variation due to changes in relative humidity.MOCAP stocks paper tapered plugs in many sizes for immediate shipment.MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need.Micro-Packs are only available online.Tolerances: Part dimensions are typical from a measured lot. Individual pieces may vary.Due to the material, this product may have minor dimensional variation due to changes in relative humidity.Flange concentricity may vary.Due to papers natural structure, the product may be oblong in free state. This will generally aid in the products retention capability.
Specifications Applications
Masking
Specifications Box Quantity
9000
Specifications Color
Tan
Specifications Flange Outer Diameter Dimension F
0.870 in | 22.1 mm
Specifications Large End Outer Diameter Dimension B
0.634 in | 16.1 mm
Specifications Length Dimension E
0.421 in | 10.7 mm
Specifications Material
Paper
Specifications Micro Pack Quantity
100
Specifications Mini Pack Quantity
1000
Specifications Small End Outer Diameter Dimension A
0.520 in | 13.2 mm
Specifications Standards
RoHS Compliant
Specifications Wall Thickness
0.025 in
Specifications Wall Thickness Tolerance
0.002
