The Telecom Data/Voice Coupling Transformer is a crucial component designed for access over leased private lines or through the dial-up switched telephone network. Compliant with FCC Part 68 standards, this transformer ensures impedance matching, isolation, repeat coil, line balancing, bridging, and hybrid circuit functionalities. With a dielectric strength of 1500V and impressive specifications such as longitudinal balance of 45 dB | 60 dB and a frequency range of 300 to 3500 Hz for Data/Voice, this transformer caters to a diverse range of applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications 0
Bridging Circuits | Hybrid Circuits | Impedance Matching | Isolation | Line Balancing | Repeat Coil
Specifications Dielectric Strength Fcc 68304
1500 V
Specifications Frequency Range Data
800 to 3500 Hz
Specifications Frequency Range Datavoice
300 to 3500 Hz
Specifications Industry Standards
FCC 68.304 for Dielectric Strength | FCC 68.310 for Longitudinal Balance
Specifications Longitudinal Balance Frequency
1000 to 4000 Hz at 45 dB | 200 to 1000 Hz at 60 dB
Specifications Maximum Input Level
5 mW
Specifications Max Dc Current
90 mA
Specifications Min Longitudinal Balance
45 dB | 60 dB
Specifications Primary Impedance
600 Ohm
Specifications Schematic
Schematic 8
Specifications Secondary Impedance
150 Ohm | 600 Ohm
Specifications Transformer Contact Type
Split
Specifications Frequency Response
±0.5 dB
Specifications Insertion Loss
1.75 dB
Specifications Return Loss
13 dB
Technical Notes 0
Primary connections shown on left side of schematics.
