Telecom Data/Voice Coupling Transformer TY Series
Telecom Data/Voice Coupling Transformer TY Series
SKU:AUD-689d9b
Enhance data & voice transmission with Telecom Data/Voice Coupling Transformer TY. Ideal for telecommunications applications. FCC Part 68 compliant.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Telecom Data/Voice Coupling Transformer TY Series
$59.99
Quantity: 1
Claim Your Seller Account
Telecom Data/Voice Coupling Transformer TY Series
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Telecom Data/Voice Coupling Transformer TY Series is expertly designed to meet the stringent requirements for data and voice transmission in telecommunications applications. With features like superior impedance matching, isolation, repeat coil functionality, and line balancing, this transformer ensures optimal performance. It boasts a dielectric strength of 1500 V, maximum input level of 5 mW, and impressive frequency response. FCC Part 68 compliant, this transformer is ideal for bridging circuits, hybrid circuits, and more.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications 0
Bridging Circuits | Hybrid Circuits | Impedance Matching | Isolation | Line Balancing | Repeat Coil
Specifications Dielectric Strength Fcc 68304
1500 V
Specifications Frequency Range Data
800 to 3500 Hz
Specifications Frequency Range Datavoice
300 to 3500 Hz
Specifications Industry Standards
FCC 68.304 for Dielectric Strength | FCC 68.310 for Longitudinal Balance
Specifications Longitudinal Balance Frequency
1000 to 4000 Hz at 45 dB | 200 to 1000 Hz at 60 dB
Specifications Maximum Input Level
5 mW
Specifications Min Longitudinal Balance
45 dB | 60 dB
Specifications Primary Impedance
600 Ohm
Specifications Schematic
Schematic 3
Specifications Secondary Impedance
600 Ohm
Specifications Frequency Response
±0.5 dB
Specifications Insertion Loss
1.0 dB
Specifications Return Loss
26 dB
Technical Notes 0
Primary connections shown on left side of schematics.
