Teledyne PeeWee 12 kVDC Receptacle Cable Assembly
Teledyne PeeWee 12 kVDC Receptacle Cable Assembly
SKU:HIG-40a697
High-voltage Teledyne PeeWee 12 kVDC Receptacle Cable Assembly for efficient, reliable connectivity in demanding applications.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Teledyne PeeWee 12 kVDC Receptacle Cable Assembly
$39.99
Quantity: 1
Claim Your Seller Account
Teledyne PeeWee 12 kVDC Receptacle Cable Assembly
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Teledyne PeeWee Series Receptacle Cable Assembly is a subminiature high-voltage connector designed for high voltage applications requiring dense electronic packaging. Featuring Teledyne Reynold's patented Advanced Interface™ method, this connector is rated at 12 kVDC at 70,000 feet with a wide temperature range of -55°C to 125°C. With a double-ended straight design and push-pull coupling, it ensures secure and efficient connectivity. The silicone rubber interface seal and encapsulation provide reliable sealing and insulation, making it ideal for diverse applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Application 0
PhotomultipliersLasersTWTPower Supplies
Body Properties Coupling Nut Material
Plastic
Cable Wire Properties Wire Diameter
0.050 in
Contact Properties Contact Design
Spherical Radius, Molded in Place
Contact Properties Contact Diameter
0.030 in | 0.762 mm
Contact Properties Contact Material
BeCu, Gold Plated
Contact Properties Contact Size
24 AWG
Contact Properties Contact Type
Male
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Double-Ended Receptacle Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
1.6 Amp
Specifications Encapsulation
Back end of connector is encapsulated with silicone rubber
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Interface Seal
Silicone Rubber
Specifications Mating Compatibility
Mates with all non-threaded Pee-Wee series plug cable assemblies.
Specifications Operating Temperature
-55 to 125 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
Yes
Specifications Series
PeeWee
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
18 kVDC
Specifications Voltage Rating
12 kVDC
Specifications Wire Insulation
Etched FEP
Specifications Wire Pn
178-8111
