Temperature Environment Input/Output Terminal Block
Temperature Environment Input/Output Terminal Block
SKU:PRO-2cf4f8
Optimize operations with our Temperature I/O Terminal Block - durable, efficient, and compliant for -15 to 55°C environments.
Regular price
$19.95
Regular price
Sale price
$19.95
Unit price
per
Initiate Order
Temperature Environment Input/Output Terminal Block
$19.95
Quantity: 1
Claim Your Seller Account
Temperature Environment Input/Output Terminal Block
$19.95
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your industrial operations with our Temperature Environment Input/Output Terminal Block. Operating within a wide temperature range of -15 to 55°C, this NPN relay terminal block by Takamisawa (Fujitsu) ensures efficient connectivity. With robust materials like Polyamide 66 and Brass for conducting plates, it meets IP20 standards, European Conformity (CE), and cULus certifications. The blue LED indicator and screwless design enhance usability, while complying with 250V AC and 24V DC requirements.
Product Specifications
Specifications 24 Volt V Direct Current Dc Rated Voltage Toleran
±10 %
Specifications Alternating Current Ac Dielectric Strength Betwee
750 V
Specifications Alternating Current Ac Rated Voltage
250 V
Specifications Applicable Cable Diameter Solid Wire 60 Degree Ce
0.6 to 1.25 mm
Specifications Applicable Cable Stranded Wire 60 Degree Celsius
22-16 AWG
Specifications Applied Relay
NYP24W-K [TAKAMISAWA (Fujitsu)]
Specifications Approval
European Conformity (CE) | Underwriters Laboratory for Canada and United States (cULus) Listed
Specifications Approximate Packaged Weight
135 g
Specifications Approximate Weight
21 g
Specifications Base Material
Polyphenylene Sulfide
Specifications Case Material
Polyphenylene Sulfide
Specifications Conducting Plate
Brass
Specifications Current Consumption
⤠8 mA
Specifications Direct Current Dc Rated Voltage
24 V | 30 V
Specifications Environment Ambient Relative Humidity Rh
35 to 85 %
Specifications Environment Ambient Temperature
-15 to 55 ºC
Specifications Environment Storage Relative Humidity Rh
35 to 85 %
Specifications Environment Storage Temperature
-25 to 65 ºC
Specifications Insulation Resistance At 500 Volt V Direct Curren
â¥1,000 MΩ
Specifications List Price
19.95 USD
Specifications Note For Terminal Pitch
Arranging over 2 units
Specifications Number Of Relay Points
1-Point
Specifications Operation Indicator
Blue Light Emitting Diode (LED)
Specifications Protection Structure
Ingress Protection (IP) 20 (International Electrotechnical Commission (IEC) Standard)
Specifications Rated Current
3 A
Specifications Rated Frequency
50 Hz | 60 Hz
Specifications Terminal Block Material
Polyamide 66
Specifications Terminal Pitch
9.0 mm
Specifications Terminal Type
Screwless
Specifications Weight
0.2 lb
