Texwrap CSS Series 9-Inch Continuous Motion Shrink Side Sealer
Texwrap CSS Series 9-Inch Continuous Motion Shrink Side Sealer
SKU:PAC-b888f6
Efficiently seal packages with precision using the Texwrap CSS Series 9-Inch Continuous Motion Shrink Side Sealer.
Regular price
$17,999.00
Regular price
Sale price
$17,999.00
Unit price
per
Initiate Order
Texwrap CSS Series 9-Inch Continuous Motion Shrink Side Sealer
$17,999.00
Quantity: 1
Claim Your Seller Account
Texwrap CSS Series 9-Inch Continuous Motion Shrink Side Sealer
$17,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Texwrap CSS Series 9-Inch Continuous Motion Shrink Side Sealer is a high-speed packaging solution designed for maximum throughput and flexibility. Featuring Texwrap's patented Motion Trim™ technology and industry-leading 10-year warranty, this sealer offers precise control over seal pressure and dwell time. Its robust construction ensures long-term reliability with minimal maintenance requirements. With features like auto spacing control, self-contained film scrap wind-up, and servo-driven end seal, this sealer accommodates various product sizes and shapes with ease, making it ideal for demanding applications in both consumer and institutional settings.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
The CSS-1407 Continuous Motion Side Seal Wrapper is Texwrap®'s latest design advance for applications requiring the moderate speed wrapping of packages where a side seal is desired.The CSS-1407 retains the hallmarks of design and proven reliability that the market has come to expect from Texwrap® - all in a brand new compact size. The 2-axis servo head combined with the 140 feet per minute conveyor speed and Texwrap®'s exclusive Motion Trim⢠technology make it the fastest and most flexible wrapper of its kind. The side seal is Texwap's exclusive Versa Seal. This device offers strong reliable seals, minimal trim requirements to save film width- all this in a device that requires very little maintenance.Simplicity and ease-of-use were paramount in the CSS-1407's design. The controls are easily accessible and intuitive to use. When combined with the color touchscreen controls on the swivel panel, the easy access sliding doors, and the easy-mount-easy-thread film carriage, this machine gives new meaning to the term âoperator-friendlyâ.The design of the CSS-1407 will appeal equally to the maintenance department. We eliminated the requirement for shop air by substituting servo drives and we provided easy access to the wrapping area by allowing the sliding operator doors to lift out completely. From true Generation 3 servo design to solid 24/7 construction, the Texwrap® CSS-1407 provides maximum reliability, ease of use, and minimum maintenance requirements resulting in the lowest total cost of ownership available on the market today.Texwrap®âs CSS Series Side Seal Wrappers can be configured with an infeed from Texwrap® to take the product from the upstream equipment and handle it to prepare the product to be wrapped and then passed through the shrink tunnel to fully automate the wrapping process.Texwrap® has developed a variety of standard infeed designs or we can create a unique design depending on the application requirement. Our CSS Series Side Seal Wrapping Turnkey Solutions provide the customer with a complete solution to reduce or dramatically reduce manual labor required for the lineâs shrink wrapping operations.Why Texwrap®?Texwrap®âs CSS Series systems employs Texwrap® Versa Seal technology that ensures the machine creates a consistent, quality seal at a high speed, and are robust enough to run continuously, 3 shifts per day, 7 days a week.Each machine is equipped with Texwrap®âs patented Motion Trim⢠technology and conveyor speeds up to 140 feet per minute. The result is a machine that maximizes speed yet minimizes wear on moving parts.Made in the U.S.A. quality and customer support, and our industry leading 10-Year BuiltBetter Backed-Better Warranty ensure the Lowest Total Cost of Ownership in the IndustryThe TVS DifferenceThe rugged yet simple design of the patented TVS (Texwrap® Versa Seal) side seal system produces the ultimate in consistent seal quality across a broad range of film types and gauges â with little or no adjustment.Using very few moving parts, no air, and an uncoated sealing element ensures consistent seal quality with very little maintenance.Texwrap® provides high-quality stand-alone machinery and systems to produce commercially attractive shrink wrapped and shrink bundled products that are protected for storage and shipping. We provide one of the most comprehensive lines of cost-effective high-speed shrink wrapping and bundling solutions for a variety of applications including L-bar sealers, continuous motion side sealers, intermittent motion side sealers, lap sealers, and vertical wrappers, as well as tunnels, conveyors, and infeeds. We also specialize in designing and building systems for e-commerce packaging, as well as custom systems to fit unique applications for a variety of shaped products.We have a network of highly-trained packaging distributor partners to better serve our customers. These partnerships ensure the best machinery and application fit, smooth startup, reliable local service, and long-term return on investment.
Features Features
Motion Trim⢠TechnologyTexwrap®'s patented technology increases throughput by the running infeed and exit conveyors while seal jaws are in motion.Standard Auto-Spacing ControlUsing vertical or horizontal photo eyes to detect leading and trailing edges of product to create consistent spacing between products.Automatic Bag Length AdjustmentHorizontal and vertical photo eyes control cross seal, and provide automatic bag length adjustmentSelf-Contained Film Scrap Wind-UpFilm scrap wind-up system with automatic speed compensating dancer bar control.Texwrap® Patented Hydraulic Cam Continuous Motion, and Servo end seal.Standard auto-spacing control using vertical and horizontal photoeyes.Horizontal and vertical photoeye controlled cross seal to provide automatic adjustment for bag length.Texwrap® Industry leading 10 year warranty.
Specifications Conveyor Speed
0 to 140 ft/min
Specifications Country Of Origin
Designed and manufactured in the USA
Specifications Maximum Center Folded Film Width
27 in
Specifications Maximum Package Height
9 in
Specifications Maximum Package Length
Infinite
Specifications Maximum Package Width
18 in
Specifications Note For Maximum Package Size
Both Height & Width cannot be at maximum dimension
Specifications Note For Wrapper Footprint
Does not include door clearance, swivel arm position, or other options
Specifications Optional Construction Material
Corrosion Resistant Heavy-Duty Welded Tubular Steel Construction for Wipe-Down Environments
Specifications Optional Single Wound Film Width
54 in
Specifications Orientation
Right or Left-hand configuration available
Specifications Standard Construction Material
Heavy-Duty Welded Tubular Steel
Specifications Wrapper Length
134 in
Specifications Wrapper Width
73 in
