Threaded Insert Ball Check Valve with Metal Seat
Threaded Insert Ball Check Valve with Metal Seat
SKU:CHE-c501f7
High-quality Threaded Insert Ball Check Valve with Metal Seat for precise flow control. Ideal for various applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Threaded Insert Ball Check Valve with Metal Seat
$29.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Ball Check Valve with Metal Seat
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Ball Check Valve with Metal Seat is crafted from high-quality 303 SS material for durability and reliability. Featuring a 304 SS ball, this valve ensures precise flow control with a CV of 0.081 and can operate at temperatures up to 300 ºF. With a maximum pressure rating of 200 psig, male threaded connection, and 5/16-24 UNF Threaded Insert O-ring seal, this valve offers secure sealing to prevent seat leakage up to 20 SSCM (max.) air flow at 25 psi differential. Measuring 0.669 inches in total length, this valve is ideal for a wide range of applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Thread Size
5/16-24
Dimensions Total Length
0.669 in
Specifications Ball Material
304 SS
Specifications Connection A
5/16-24 UNF Threaded Insert O-ring seal
Specifications Cv
0.081
Specifications Material
303 SS
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
