Threaded Insert Ball Check Valve with Metal Seat
Threaded Insert Ball Check Valve with Metal Seat
SKU:CHE-b0ba05
High-quality Threaded Insert Ball Check Valve with Metal Seat for reliable flow control in industrial applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Threaded Insert Ball Check Valve with Metal Seat
$49.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Ball Check Valve with Metal Seat
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Ball Check Valve with Metal Seat is a premium quality valve crafted from 303 SS and features a Viton seal for enhanced durability. With a CV of 0.190 and a maximum operating pressure of 200 psig, this valve ensures reliable performance. Its 304 SS ball and Male Thread connection make it suitable for a wide range of applications. Designed to withstand temperatures up to 300°F, this valve minimizes seat leakage to 20 SSCM (max.) air flow at 25 psi differential. Trust in this valve for efficient and secure flow control in industrial settings.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cv
0.190
Specifications Material
303 SS
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
