Threaded Insert Ball Check Valve with Metal Seat
Threaded Insert Ball Check Valve with Metal Seat
SKU:CHE-4c4fce
Durable Threaded Insert Ball Check Valve with Metal Seat, ideal for high-pressure applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Threaded Insert Ball Check Valve with Metal Seat
$29.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Ball Check Valve with Metal Seat
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Ball Check Valve with Metal Seat is expertly crafted from 303 SS with a durable 304 SS ball. Designed for efficiency, it features a CV of 0.190, handles temperatures up to 300°F, and sustains a maximum pressure of 200 psig. With a male thread size of 7/16-20 UNF and an O-ring seal, this valve ensures minimal seat leakage (20 SSCM max. air flow at 25 psi differential). The compact dimensions of 0.781 inches total length make it versatile for various applications, meeting the stringent requirements of government and institutional buyers.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cv
0.190
Specifications Material
303 SS
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
