Threaded Insert Ball Check Valve with Metal Seat
Threaded Insert Ball Check Valve with Metal Seat
SKU:CHE-6efff2
High-performance Threaded Insert Ball Check Valve with Metal Seat for precise flow control. Durable, reliable, and efficient design.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Threaded Insert Ball Check Valve with Metal Seat
$34.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Ball Check Valve with Metal Seat
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Ball Check Valve with Metal Seat is precision-engineered with materials meeting stringent standards. Crafted with 303 SS for durability, Viton seal for superior performance, and 304 SS ball for reliability. With a CV of 0.190 and maximum operating pressure of 200 psig, this valve ensures efficient flow control. Designed for temperatures up to 300°F, it minimizes seat leakage to 20 SSCM. The 7/16-20 UNF Threaded Insert O-ring seal provides a secure connection. Ideal for industrial applications requiring precision and durability.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cv
0.190
Specifications Material
303 SS
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
