Threaded Insert Ball Check Valves with Metal Seat
Threaded Insert Ball Check Valves with Metal Seat
SKU:CHE-e18a2e
Premium Threaded Ball Check Valves for precise flow control in industrial environments.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Threaded Insert Ball Check Valves with Metal Seat
$39.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Ball Check Valves with Metal Seat
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Ball Check Valves with Metal Seat are expertly crafted from durable Brass with a 304 Stainless Steel ball. Featuring a low CV of 0.02, a maximum temperature of 150°F, and a cracking pressure of 2 psid, these valves ensure reliable performance. Ideal for applications requiring a secure seal, they have a male 10-32 UNF Threaded Insert design with an O-ring seal. With a total length of 0.425 inches, these valves deliver precision and efficiency, making them a top choice for industrial settings.
Product Specifications
Dimensions Thread Size
10-32
Dimensions Total Length
0.425 in
Specifications Ball Material
304 SS
Specifications Connection A
10-32 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
2 psid
Specifications Cv
0.02
Specifications Material
Brass
Specifications Maximum Operating Pressure
125 psig
Specifications Maximum Temperature
150 ºF
Specifications Screened
None
Specifications Thread
Male
