Threaded Insert Ball Type Check Valves with Metal Seat
Threaded Insert Ball Type Check Valves with Metal Seat
SKU:CHE-1075f2
Precision-engineered Threaded Insert Ball Type Check Valves with Metal Seat for reliable flow control in industrial settings.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Threaded Insert Ball Type Check Valves with Metal Seat
$29.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Ball Type Check Valves with Metal Seat
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Ball Type Check Valves with Metal Seat are expertly crafted with 303 SS body and a 304 SS ball for reliable performance. With a CV of 0.02 and a maximum operating pressure of 125 psig, these valves ensure precise flow control. Featuring a male thread and a 10-32 UNF Threaded Insert O-ring seal, these valves offer a secure connection. The metal-to-metal seat design guarantees minimal seat leakage of 20 SSCM at 25 psi, making them ideal for industrial applications. Additionally, these valves are designed to withstand temperatures up to 150°F, providing durability under varying conditions.
Product Specifications
Dimensions Thread Size
10-32
Dimensions Total Length
0.425 in
Specifications Ball Material
304 SS
Specifications Connection A
10-32 UNF Threaded Insert O-ring seal
Specifications Cv
0.02
Specifications Material
303 SS
Specifications Maximum Operating Pressure
125 psig
Specifications Maximum Temperature
150 ºF
Specifications Screened
None
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
