Threaded Insert Ball Type Check Valves with Metal Seat
Threaded Insert Ball Type Check Valves with Metal Seat
SKU:CHE-0e4812
Reliable Threaded Insert Ball Type Check Valves with Metal Seat for industrial applications. Brass construction with Viton seal, 304 SS ball, and 5/16-24 UNF Threaded Insert O-ring seal.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Threaded Insert Ball Type Check Valves with Metal Seat
$39.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Ball Type Check Valves with Metal Seat
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Ball Type Check Valves with Metal Seat offer superior performance with a durable brass construction and Viton seal, ensuring reliable operation. With a maximum temperature of 300°F and operating pressure of 200 psig, these valves are designed for efficiency and longevity. The 304 SS ball material and precise 5/16-24 UNF Threaded Insert O-ring seal deliver a tight seal, making them ideal for various industrial applications requiring secure valve performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Thread Size
5/16-24
Dimensions Total Length
0.669 in
Specifications Ball Material
304 SS
Specifications Connection A
5/16-24 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
0 psid
Specifications Cv
0.081
Specifications Material
Brass
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Thread
Male
