Threaded Insert Check Valve, Ball Type - Metal Seat
Threaded Insert Check Valve, Ball Type - Metal Seat
SKU:CHE-e48bf3
High-quality Threaded Insert Check Valve with Metal Seat, designed for precision & durability in demanding applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Threaded Insert Check Valve, Ball Type - Metal Seat
$29.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Check Valve, Ball Type - Metal Seat
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Check Valve, Ball Type with Metal Seat is a high-quality valve designed for precision and durability. Crafted from 303 SS material with a Viton seal and a 304 SS ball, this valve ensures reliable performance. With a CV of 0.081, maximum temperature of 300 °F, and maximum operating pressure of 200 psig, it excels in demanding applications. The male threaded connection and 5/16-24 UNF Threaded Insert O-ring seal provide secure installation. Experience minimal seat leakage of 20 SSCM air flow at 25 psi differential. Compliant with industry standards, this valve is ideal for both consumer and institutional use.
Product Specifications
Dimensions Thread Size
5/16-24
Dimensions Total Length
0.669 in
Specifications Ball Material
304 SS
Specifications Connection A
5/16-24 UNF Threaded Insert O-ring seal
Specifications Cv
0.081
Specifications Material
303 SS
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
