Threaded Insert Check Valves, Ball Type - Metal Seat
Threaded Insert Check Valves, Ball Type - Metal Seat
SKU:CHE-80b8e2
Premium Threaded Insert Check Valves with Metal Seat for superior control and durability. Ideal for institutions.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Threaded Insert Check Valves, Ball Type - Metal Seat
$49.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Check Valves, Ball Type - Metal Seat
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Check Valves, Ball Type with Metal Seat are expertly crafted with high-quality 303 SS material, ensuring durability and reliability in diverse applications. Featuring a Viton seal and 304 SS ball, these valves offer exceptional performance with a maximum operating pressure of 125 psig and a cracking pressure of 2 psid. Ideal for institutional settings, these valves guarantee precise control and optimal flow regulation. Compliant with federal procurement standards, GSA requirements, and industry certifications, they are a trusted choice for demanding environments.
Product Specifications
Dimensions Thread Size
10-32
Dimensions Total Length
0.425 in
Specifications Ball Material
304 SS
Specifications Connection A
10-32 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
2 psid
Specifications Cv
0.02
Specifications Material
303 SS
Specifications Maximum Operating Pressure
125 psig
Specifications Maximum Temperature
150 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Thread
Male
