Threaded Insert Check Valves, Brass Ball Type with Metal Seat
Threaded Insert Check Valves, Brass Ball Type with Metal Seat
SKU:CHE-910f1b
Reliable Brass Check Valves with Viton seal, ideal for efficient flow control. Maximum pressure 200 psig.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Threaded Insert Check Valves, Brass Ball Type with Metal Seat
$45.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Check Valves, Brass Ball Type with Metal Seat
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Check Valves feature a durable Brass construction with a Viton seal, providing reliable performance in various applications. With a 304 SS Ball and a maximum temperature of 300°F, these valves ensure efficient flow control and safety. Designed with a male thread and 5/16-24 UNF Threaded Insert O-ring seal, they offer a cracking pressure of 2 psid and a maximum operating pressure of 200 psig. Trust in the quality and precision of these valves for your industrial needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Thread Size
5/16-24
Dimensions Total Length
0.669 in
Specifications Ball Material
304 SS
Specifications Connection A
5/16-24 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
2 psid
Specifications Cv
0.081
Specifications Material
Brass
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Thread
Male
