Threaded Insert Check Valves, Metal Ball Type with Viton Seal
Threaded Insert Check Valves, Metal Ball Type with Viton Seal
SKU:CHE-16af5f
High-performance Threaded Insert Check Valves with Viton Seal, ideal for industrial applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Threaded Insert Check Valves, Metal Ball Type with Viton Seal
$49.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Check Valves, Metal Ball Type with Viton Seal
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Check Valves are engineered with precision using 303 SS material and a durable Viton seal. With a CV of 0.190 and a maximum temperature of 300°F, these valves ensure optimal performance under pressure. Featuring a Metal Ball Type design and leakage resistance of 20 SSCM at 25 psi, they are ideal for industrial applications requiring reliability and efficiency. Compliant with federal procurement standards and industry-specific certifications, these valves offer long-lasting durability and consistent performance.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cv
0.190
Specifications Material
303 SS
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
