Threaded Insert Check Valves - Metal Seated Ball Type
Threaded Insert Check Valves - Metal Seated Ball Type
SKU:CHE-9db807
High-performance Threaded Insert Check Valves for precision and reliability in high-pressure applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Threaded Insert Check Valves - Metal Seated Ball Type
$45.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Check Valves - Metal Seated Ball Type
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Check Valves feature a durable construction with a 303 SS body and a 304 SS ball that ensures long-lasting performance. With a CV of 0.190 and a maximum operating pressure of 200 psig, these valves are designed to withstand high-pressure applications up to 300 °F. The male threaded insert with an O-ring seal provides secure connections. Additionally, these valves offer minimal seat leakage at 20 SSCM, making them ideal for applications requiring precision and reliability. Compliant with industry standards for quality and performance, these valves are a dependable choice for various industrial and institutional needs.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cv
0.190
Specifications Material
303 SS
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
