Threaded Insert Check Valves with Fluorocarbon Seal

Name: Threaded Insert Check Valves with Fluorocarbon Seal
Brand: O'Keefe Controls Co.
SKU: CHE-ab7f61
Price: 29.99 USD
Availability: OutOfStock

SKU:CHE-ab7f61

Optimize flow control with our precision Threaded Insert Check Valves. Ideal for industrial use, ensuring durability and efficiency.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Enhance fluid control with our Threaded Insert Check Valves featuring a durable 440C-SS ball, 303 SS construction, and a reliable Fluorocarbon seal. Designed for a maximum operating pressure of 1400 kPa, precise flow control, and minimal leakage, these valves offer long-lasting performance at a competitive cost. Ideal for industrial applications requiring secure sealing and efficient operation.

Product Specifications

Dimensions Nose Diameter

4.45 mm

Dimensions Orifice Diameter

0.04 in | 1.02 mm

Dimensions Thread Size

Dimensions Total Length

12.7 mm

Dimensions Width Across Flats Hex

3 mm

Features Features

All metal construction option Long life operation Low cost

Specifications Ball Material

440C-SS

Specifications Connection A

M6 Threaded Insert O-Ring seal

Specifications Cv

0.036

Specifications Hex Type

Internal

Specifications Material

303 SS

Specifications Maximum Operating Pressure

1400 kPa

Specifications Nominal Orifice Size

Specifications Screened

None

Specifications Seal Material

Fluorocarbon

Specifications Seat Leakage

20 SSCM (max.) air flow at 25 psi differential

Specifications Thread

Male
