Threaded Insert Check Valves with Nose Seal
Threaded Insert Check Valves with Nose Seal
SKU:CHE-d9a1ae
High-performing Threaded Insert Check Valves with Nose Seal for reliable and efficient fluid control.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.



The Threaded Insert Check Valves with Nose Seal are designed for reliable performance in various applications. Featuring fluorocarbon seal material, brass construction, and a low-cost metal to elastomeric seat design, these valves ensure long service life and efficient operation. With a maximum operating pressure of 875 kPa and a maximum temperature of 65°F, they meet stringent industry standards for durability and performance.
Product Specifications
Dimensions Nose Diameter
3.10 mm
Dimensions Orifice Diameter
0.027 in | 0.69 mm
Dimensions Thread Size
M5
Dimensions Total Length
10.8 mm
Dimensions Width Across Flats Hex
2.5 mm
Features Features
All metal construction option Long life operation Low cost
Specifications Ball Material
Nitrile
Specifications Connection A
M5 Threaded Insert O-Ring seal
Specifications Cv
0.017
Specifications Hex Type
Internal
Specifications Material
Brass
Specifications Maximum Operating Pressure
875 kPa
Specifications Maximum Temperature
65 ºF
Specifications Nominal Orifice Size
27
Specifications Screened
None
Specifications Seal Material
Fluorocarbon
Specifications Seat Leakage
6 SCCM (max.) air flow at greater than 50 psi differential
Specifications Thread
Male
