Threaded Insert Check Valves with Nose Seal
Threaded Insert Check Valves with Nose Seal
SKU:CHE-f1d18e
Enhance fluid control with precision Threaded Insert Check Valves for optimal performance and longevity.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Threaded Insert Check Valves with Nose Seal
$39.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Check Valves with Nose Seal
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your fluid control systems with our Threaded Insert Check Valves featuring a Fluorocarbon seal and Nitrile ball material for reliable performance. Made of 303 SS, these valves offer a Nominal Orifice Size of 15 and a CV of 0.005. With a maximum operating pressure of 875 kPa, these valves ensure efficient flow control at temperatures up to 65°F. The M8 Threaded Insert O-Ring seal enhances seal integrity, minimizing seat leakage to 6 SCCM. Enjoy long-lasting operation and cost-effectiveness with the all-metal construction option.
Product Specifications
Dimensions Nose Diameter
5.59 mm
Dimensions Orifice Diameter
0.015 in | 0.38 mm
Dimensions Thread Size
M8
Dimensions Total Length
16.3 mm
Dimensions Width Across Flats Hex
4 mm
Features Features
All metal construction option Long life operation Low cost
Specifications Ball Material
Nitrile
Specifications Connection A
M8 Threaded Insert O-Ring seal
Specifications Cv
0.005
Specifications Hex Type
Internal
Specifications Material
303 SS
Specifications Maximum Operating Pressure
875 kPa
Specifications Maximum Temperature
65 ºF
Specifications Nominal Orifice Size
15
Specifications Screened
None
Specifications Seal Material
Fluorocarbon
Specifications Seat Leakage
6 SCCM (max.) air flow at greater than 50 psi differential
Specifications Thread
Male
