Threaded Insert Check Valves with Nose Seal
Threaded Insert Check Valves with Nose Seal
SKU:CHE-32b1c7
Reliable Threaded Insert Check Valves with Nose Seal for precise flow control and durability in industrial applications.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.



The Threaded Insert Check Valves with Nose Seal are designed for optimal performance in industrial applications requiring reliable sealing. Constructed with 303 SS material and featuring a Fluorocarbon seal and Nitrile ball, these valves ensure durability and effective flow control. With a maximum operating pressure of 875 kPa and a maximum temperature of 65 °F, these valves offer secure sealing and precision. The metal to elastomeric seat design minimizes seat leakage to 6 SCCM (max.), meeting stringent industrial standards for air flow control. Invest in these check valves for long-lasting, cost-effective solutions in fluid handling systems.
Product Specifications
Dimensions Nose Diameter
5.59 mm
Dimensions Orifice Diameter
0.022 in | 0.56 mm
Dimensions Thread Size
M8
Dimensions Total Length
16.3 mm
Dimensions Width Across Flats Hex
4 mm
Features Features
All metal construction option Long life operation Low cost
Specifications Ball Material
Nitrile
Specifications Connection A
M8 Threaded Insert O-Ring seal
Specifications Cv
0.011
Specifications Hex Type
Internal
Specifications Material
303 SS
Specifications Maximum Operating Pressure
875 kPa
Specifications Maximum Temperature
65 ºF
Specifications Nominal Orifice Size
22
Specifications Screened
None
Specifications Seal Material
Fluorocarbon
Specifications Seat Leakage
6 SCCM (max.) air flow at greater than 50 psi differential
Specifications Thread
Male
