Threaded Insert Check Valves with Nose Seal
Threaded Insert Check Valves with Nose Seal
SKU:CHE-7aeb4c
Reliable Threaded Insert Check Valves with Buna-N Ball Material, ideal for precision air flow control.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Threaded Insert Check Valves with Nose Seal
$34.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Check Valves with Nose Seal
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Threaded Insert Check Valves with Nose Seal are designed for reliability and precision. Constructed with Buna-N Ball Material and 303 SS, these valves ensure a long life operation with low cost. With a Maximum Operating Pressure of 125 psig and a Maximum Temperature of 180°F, these valves offer optimal performance in various applications. Their metal to elastomeric seat design minimizes seat leakage to 6 SCCM, meeting stringent industry standards for air flow control.
Product Specifications
Dimensions Nose Diameter
0.125 in
Dimensions Orifice Diameter
0.031 in
Dimensions Thread Length
0.320 in
Dimensions Thread Size
10-32
Dimensions Total Length
0.425 in
Dimensions Width Across Flats Hex
3/32 in
Features Features
All metal construction option Long life operation Low cost
Specifications Ball Material
Buna-N
Specifications Connection A
10-32 UNF Threaded Insert
Specifications Cv
0.02
Specifications Hex Type
Internal
Specifications Material
303 SS
Specifications Maximum Operating Pressure
125 psig
Specifications Maximum Temperature
180 ºF
Specifications Nominal Orifice Size
31
Specifications Screened
None
Specifications Seat Leakage
6 SCCM (max.) air flow at greater than 50 psi differential
Specifications Thread
Male
