Threaded Insert Metal Seat Ball Type Check Valves
Threaded Insert Metal Seat Ball Type Check Valves
SKU:CHE-53e8fb
Premium Threaded Insert Metal Seat Ball Type Check Valves for precise flow control in industrial settings.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Threaded Insert Metal Seat Ball Type Check Valves
$34.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Metal Seat Ball Type Check Valves
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Threaded Insert Metal Seat Ball Type Check Valves are expertly crafted with 303 SS material, Viton seal, and 304 SS ball, ensuring superior performance under pressure. With a CV of 0.02, maximum temperature of 150°F, and maximum operating pressure of 125 psig, these valves offer reliable flow control. The male 10-32 UNF Threaded Insert with O-ring seal provides secure connections, while the seat leakage rate of 20 SSCM air flow at 25 psi ensures efficiency. Perfect for industrial applications that demand precision and durability.
Product Specifications
Dimensions Thread Size
10-32
Dimensions Total Length
0.425 in
Specifications Ball Material
304 SS
Specifications Connection A
10-32 UNF Threaded Insert O-ring seal
Specifications Cv
0.02
Specifications Material
303 SS
Specifications Maximum Operating Pressure
125 psig
Specifications Maximum Temperature
150 ºF
Specifications Screened
None
Specifications Seal Material
Viton
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
