Threaded Insert Metal Seat Check Valves, Ball Type - Brass, 304 SS
Threaded Insert Metal Seat Check Valves, Ball Type - Brass, 304 SS
SKU:CHE-8236a4
Premium Threaded Insert Metal Seat Check Valves for reliable performance & precise control.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Threaded Insert Metal Seat Check Valves, Ball Type - Brass, 304 SS
$29.99
Quantity: 1
Claim Your Seller Account
Threaded Insert Metal Seat Check Valves, Ball Type - Brass, 304 SS
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Threaded Insert Metal Seat Check Valves feature a sturdy construction with a Brass body and a 304 Stainless Steel ball, ensuring durability and reliable performance. With a CV of 0.02, these valves can handle a maximum temperature of 150ºF and a maximum operating pressure of 125 psig. The male 10-32 UNF Threaded Insert with O-ring seal connection provides secure installation. Ideal for various applications requiring precise control and protection against backflow.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Thread Size
10-32
Dimensions Total Length
0.425 in
Specifications Ball Material
304 SS
Specifications Connection A
10-32 UNF Threaded Insert O-ring seal
Specifications Cracking Pressure
6 psid
Specifications Cv
0.02
Specifications Material
Brass
Specifications Maximum Operating Pressure
125 psig
Specifications Maximum Temperature
150 ºF
Specifications Screened
None
Specifications Thread
Male
