Threaded Metal Seat Check Valves, Ball Type
Threaded Metal Seat Check Valves, Ball Type
SKU:CHE-347acf
High-performance Threaded Metal Seat Check Valves, Ball Type, with 303 SS construction and 304 SS ball for efficient flow control.
Regular price
$32.50
Regular price
Sale price
$32.50
Unit price
per
Initiate Order
Threaded Metal Seat Check Valves, Ball Type
$32.50
Quantity: 1
Claim Your Seller Account
Threaded Metal Seat Check Valves, Ball Type
$32.50
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Threaded Metal Seat Check Valves, Ball Type, are designed for reliable flow control in various applications. Constructed with high-quality 303 SS material and a durable 304 SS ball, these valves ensure superior performance under pressure. With a CV of 0.190, maximum temperature of 300°F, and maximum pressure of 200 psig, they excel in demanding environments. The male threaded insert with O-ring seal provides secure connections, while the minimal seat leakage of 20 SSCM at 25 psi enhances efficiency. From precise dimensions to robust build, these valves meet stringent industry standards for durability and performance.
Product Specifications
Dimensions Thread Size
7/16-20
Dimensions Total Length
0.781 in
Specifications Ball Material
304 SS
Specifications Connection A
7/16-20 UNF Threaded Insert O-ring seal
Specifications Cv
0.190
Specifications Material
303 SS
Specifications Maximum Operating Pressure
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Screened
None
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
Specifications Thread
Male
