Throttle Master 1/2" x 1/2" Female NPT Globe Needle Valve-PP
Throttle Master 1/2" x 1/2" Female NPT Globe Needle Valve-PP
SKU:PLA-7c17e0
Achieve precise flow control with the Throttle Master 1/2" Globe Needle Valve-PP for corrosive fluids. Metal-free, bubble-tight design.
Regular price
$76.50
Regular price
Sale price
$76.50
Unit price
per
Initiate Order
Throttle Master 1/2" x 1/2" Female NPT Globe Needle Valve-PP
$76.50
Quantity: 1
Claim Your Seller Account
Throttle Master 1/2" x 1/2" Female NPT Globe Needle Valve-PP
$76.50
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Throttle Master 1/2" x 1/2" Female NPT Globe Needle Valve-PP offers precise flow control and fine adjustment for corrosive and high purity fluids. With a globe pattern needle finish, SPI/SPE #1 construction, and bubble-tight, low torque shut-off design, this valve ensures long-term performance. It features a 24 pitch metering thread for 20% finer control, PTFE sealing for chemical resistance, and high purity integrally designed panel mounting. This valve is metal-free, elastomer-free, and lubricant-free, guaranteeing no corrosion or contamination. Suitable for panel thicknesses from 1/16" to 1/2", it meets industry-standard requirements for PVC, CPVC, Polypro, and PVDF materials.
Product Specifications
Materials Of Construction 0
Needle Finish, SPI/SPE # 1Bubble tight, low torque shut-off. Proven three prong, star handleTri-Oval geometryFast open/close operationFine metering control. 24 pitch metering thread20% finer control adjustment Integrally designed panel mountingNo fasteners requiredMounts to panel thicknesses from 1/32" to 1/2" PTFE SealedChemical resistanceHigh Purity No Elastomers (O-rings), metals or lubricantsNo corrosionNo contamination Materials of Construction.PVC is NSF Std 14 & 61 RatedCPVC is NSF Std 14 & 61 RatedPP is natural (unpigmented), reinforcedPVDF is NSF Std 14 & 61 Rated
Specifications Cv Factor
0.620
Specifications Inlet X Outlet
1/2" Female NPT
Specifications List Price
76.5 USD
Specifications Materials
Polypro (PP), PTFE Seal
Specifications Shipping Note
We will let you know the shipping charges once we receive the order.
Specifications Style
Globe, Straight Pattern
