TiN Coated TKF16R100-S Right Hand Grooving/Cut-Off Insert

Name: TiN Coated TKF16R100-S Right Hand Grooving/Cut-Off Insert
Brand: Penn Tool Co.
SKU: CUT-249d9c
Price: 25.99 USD
Availability: OutOfStock

SKU:CUT-249d9c

Achieve precision in grooving and cut-off applications with the TiN Coated TKF16R100-S Insert, suitable for alloy and stainless steel. Improve cutting speeds and performance with Grade WM25.

$25.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The TiN Coated TKF16R100-S Right Hand Grooving/Cut-Off Insert is expertly designed for precise grooving and parting applications in alloy and stainless steel. With a Titanium Nitride (TiN) coating, this insert offers enhanced durability and wear resistance, ensuring optimal performance at cutting speeds of 80 to 140 m/min for stainless steel and 120 to 180 m/min for steel. The Grade WM25 construction makes it ideal for semi-finishing steel and stainless steel, providing reliable results in various machining operations.

Product Specifications

Technical Specs Brands

Penn Tool Co. | Precise

Technical Specs Coating

Titanium Nitride (TiN)

Technical Specs Cutting Speed For Stainless Vc

80 to 140 m/min

Technical Specs Cutting Speed For Steel Vc

120 to 180 m/min

Technical Specs Maximum Diameter

16 mm

TiN Coated TKF16R100-S Right Hand Grooving/Cut-Off Insert
