Torlon 4203 Polyamide-Imide Round Bar
Torlon 4203 Polyamide-Imide Round Bar
SKU:SHA-7b1246
High-performance Torlon 4203 Round Bar for extreme heat applications. Superior strength & dimensional stability up to 500°F.
Regular price
$35.99
Regular price
Sale price
$35.99
Unit price
per
Initiate Order
Torlon 4203 Polyamide-Imide Round Bar
$35.99
Quantity: 1
Claim Your Seller Account
Torlon 4203 Polyamide-Imide Round Bar
$35.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Torlon 4203 Polyamide-Imide Round Bar is a high-performance engineering material designed for demanding applications. With a specific gravity of 1.41 and exceptional mechanical properties like a tensile strength of 20,000 psi and a heat deflection temperature of 532°F, this bar offers superior strength and dimensional stability up to 500°F. It excels in high-temperature electrical connectors, chip nests & sockets, and mandrels, making it ideal for industries requiring durability and reliability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Applications
High temperature electrical connectors.Chip nests & sockets.Can mandrel
Characteristics Characteristics
Maintains strength & stiffness to 500ºF.Minimal expansion rate to 500ºF.Able to endure harsh thermal, chemical and stress conditions.
Specifications Availability
stock
Specifications Coefficient Of Friction Static
0.35
Specifications Color
Brown/Yellow
Specifications Compressive Modulus
479000 psi
Specifications Compressive Strength
23900 psi
Specifications Dielectric Strength
580 V/mil
Specifications Flammability At 125 Ul94
V0
Specifications Flexural Modulus
600000 psi
Specifications Flexural Strength
23900 psi
Specifications Glass Transition Temperature
527 ºF
Specifications Hardness Rockwell
E80 / M120
Specifications Heat Deflection Temperature 264 Psi
532 ºF
Specifications Izod Impact Strength Notched Astm D256
2.0
Specifications Material
PAI
Specifications Minimum Order
1
Specifications Optional Lengths
1', 4'
Specifications Specific Gravity
1.41
Specifications Standard Length
8' ft
Specifications Tensile Elongation Break
10%
Specifications Tensile Modulus
600000 psi
Specifications Tensile Strength
20000 psi
Specifications Tolerance
+only in
Specifications Water Absorption 24 Hrs
0.40 %
Specifications Water Absorption Saturation Astm D570
1.70
