Torlon® 4203 Polyamide-imide Round Bar
Torlon® 4203 Polyamide-imide Round Bar
SKU:SHA-bd8e45
High-performance Torlon® 4203 PAI Round Bar for demanding applications. Withstands up to 500ºF. Ideal for electrical connectors & chip sockets.
Regular price
$28.99
Regular price
Sale price
$28.99
Unit price
per
Initiate Order
Torlon® 4203 Polyamide-imide Round Bar
$28.99
Quantity: 1
Claim Your Seller Account
Torlon® 4203 Polyamide-imide Round Bar
$28.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Torlon® 4203 PAI Round Bar is a high-performance engineering plastic designed for demanding applications. With excellent thermal and chemical resistance, this brown/yellow round bar maintains strength & stiffness up to 500ºF. It offers a low coefficient of friction, high compressive strength, and remarkable toughness, making it ideal for high temperature electrical connectors, chip nests & sockets, and mandrels. Meet stringent requirements with this reliable Torlon® PAI round bar.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Applications
High temperature electrical connectors.Chip nests & sockets.Can mandrel
Characteristics Characteristics
Maintains strength & stiffness to 500ºF.Minimal expansion rate to 500ºF.Able to endure harsh thermal, chemical and stress conditions.
Specifications Availability
3-5 days
Specifications Coefficient Of Friction Static
0.35
Specifications Color
Brown/Yellow
Specifications Compressive Modulus
479000 psi
Specifications Compressive Strength
23900 psi
Specifications Dielectric Strength
580 V/mil
Specifications Flammability At 125 Ul94
V0
Specifications Flexural Modulus
600000 psi
Specifications Flexural Strength
23900 psi
Specifications Glass Transition Temperature
527 ºF
Specifications Hardness Rockwell
E80 / M120
Specifications Heat Deflection Temperature 264 Psi
532 ºF
Specifications Izod Impact Strength Notched Astm D256
2.0
Specifications Material
PAI
Specifications Minimum Order
1
Specifications Specific Gravity
1.41
Specifications Standard Length
8' ft
Specifications Tensile Elongation Break
10%
Specifications Tensile Modulus
600000 psi
Specifications Tensile Strength
20000 psi
Specifications Tolerance
+only in
Specifications Water Absorption 24 Hrs
0.40 %
Specifications Water Absorption Saturation Astm D570
1.70
